Description Of The Service
Atlas Elevator Ltd specializes in the supply, installation, modernization, and maintenance of elevators and escalators for both commercial and residential buildings. We design and deliver customized solutions that enhance accessibility, meet building requirements, and ensure reliable vertical transportation.
Our experienced team combines advanced technology, strict safety compliance, and customer-focused service to provide a seamless experience—whether it’s a high-rise commercial tower, a shopping mall, or a private residence.
Our Services Include
We have the expertise to deliver a wide range of elevator and escalator solutions tailored to each client’s needs:
Solutions & Benefits
We pride ourselves on providing flexible, cost-effective, and reliable solutions for buildings of all sizes. Our services are designed to adapt to different budgets without compromising quality, safety, or performance.
Benefit Of Service
Working Process
We have a track record of delivering significant extension and expansion projects for buildings as diverse as schools, leisure centres, churches, and industrial units – providing much needed space and new facilities for our clients. We are used to working in close proximity to occupied buildings.
1.Consultation
2.Design & Work
3.Complete & Maintenance
We are committed to keeping our sites segregated, secure and safe and regularly obtain Considerate Contractor accreditation for our projects.
Frequently Asked Questions
How does the whole process work?
What sort of aftercare can you expect?
What other services do you offer?
How are payments handled and dealt with?
categories
why choose us
download brochure
Please download our document to see specific data of the aservice and how we work.
Let’s Start Work Together
House # 15, Road # 08
(3rd Floor), Nikunjo-02, Dhaka-1229, Bangladesh.
atlaselevatorltd@gmail.com
10.00AM – 8.00PM
Building Type
Low to mid-rise buildings
Travel
*Up to 60 feet of rise
Capacity
*Up to 5,000 lbs
Speed
Up to 150 FPM
*Based on standard designs. Custom solutions exceeding these parameters may be available. Contact a sales representative to learn more.
This application requires a well hole. All Schumacher In-Ground Hydraulic Elevators offer a PVC liner that provides protection from galvanic or electrolytic corrosion and prevents oil from leaking into the soil.
Advantages
- Shortest design time and lead time
- Simplest elevator package to install
- Minimal pit and overhead requirements
- Available for both low and high capacity
- Non-proprietary equipment
Standard Drawings & Specs
Standard Cab
Typically used for moving passengers.
EXTENDED CAB
IBC Gurney Compliant. Often used as building service elevators.
| Capacity (lb.) | Cab Layout | Openings | IBC Gurney Compliant | Opening Type | Hoistway (W x D) | Interior (W x D) | Door Width | DWG | |
|---|---|---|---|---|---|---|---|---|---|
| 2000 | Standard | F | No | SS | 7'4" x 5'9" | 5'8" x 4'3" | 3'0" |
|
|
| 2000 | Standard | F | No | TS | 7'4" x 6'0" | 5'8" x 4'3" | 4'0" |
|
|
| 2000 | Standard | F & R | No | SS | 7'4" x 6'6 1/2" | 5'8" x 4'3" | 3'0" |
|
|
| 2000 | Standard | F & R | No | TS | 7'4" x 7'0 1/2" | 5'8" x 4'3" | 4'0" |
|
|
| 2500 | Standard | F | No | SS or CP | 8'4" x 5'9" | 6'8" x 4'3" | 3'6" |
|
|
| 2500 | Standard | F | No | TS | 8'4" x 6'0" | 6'8" x 4'3" | 4'6" |
|
|
| 2500 | Standard | F & R | No | SS | 8'4" x 6'6 1/2" | 6'8" x 4'3" | 3'6" |
|
|
| 2500 | Standard | F & R | No | TS | 8'4" x 7'0 1/2" | 6'8" x 4'3" | 4'6" |
|
|
| 3000 | Standard | F | No | SS or CP | 8'4" x 6'3" | 6'8" x 4'9" | 3'6" |
|
|
| 3000 | Standard | F | No | TS | 8'4" x 6'6" | 6'8" x 4'9" | 4'6" |
|
|
| 3000 | Standard | F & R | No | SS or CP | 8'4" x 7'0 1/2" | 6'8" x 4'9" | 3'6" |
|
|
| 3000 | Standard | F & R | No | TS | 8'4" x 7'6 1/2" | 6'8" x 4'9" | 4'6" |
|
|
| 3500 | Standard | F |
Yes |
SS or CP | 8'4" x 6'11" | 6'8" x 5'5" | 3'6" |
|
|
| 3500 | Standard | F | Yes | TS | 8'4" x 7'2" | 6'8" x 5'5" | 4'6" |
|
|
| 3500 | Standard | F & R | Yes | SS or CP | 8'4" x 7'8 1/2" | 6'8" x 5'5" | 3'6" |
|
|
| 3500 | Standard | F & R | Yes | TS | 8'4" x 8'2 1/2" | 6'8" x 5'5" | 4'6" |
|
|
| 3500 | Extended | F | Yes | TS | 7'4" x 8'5" | 5'8" x 6'8" | 4'0" |
|
|
| 3500 | Extended | F & R | Yes | TS | 7'4" x 9'5 1/2" | 5'8" x 6'8" | 4'0" |
|
|
| 4000 | Standard | F | Yes | SS or CP | 9'4" x 6'11" | 7'8" x 5'5" | 4'0" |
|
|
| 4000 | Standard | F | Yes | TS | 9'4" x 7'2" | 7'8" x 5'5" | 5'0" |
|
|
| 4000 | Standard | F & R | Yes | SS or CP | 9'4" x 7'8 1/2" | 7'8" x 5'5" | 4'0" |
|
|
| 4000 | Standard | F & R | Yes | TS | 9'4" x 8'2 1/2" | 7'8" x 5'5" | 5'0" |
|
|
| 4000 | Extended | F | Yes | TS | 7'4" x 9'2" | 5'8" x 7'5" | 4'0" |
|
|
| 4000 | Extended | F & R | Yes | TS | 7'4" x 10'2 1/2" | 5'8" x 7'5" | 4'0" |
|
|
| 4500 | Extended | F | Yes | TS | 7'4" x 9'6 1/2" | 5'8" x 7'9 1/2" | 4'0" |
|
|
| 4500 | Extended | F & R | Yes | TS | 7'4" x 10'7" | 5'8" x 7'9 1/2" | 4'0" |
|
|
| 5000 | Extended | F | Yes | TS | 7'4" x 10'2" | 5'8" x 8'5" | 4'0" |
|
|
| 5000 | Extended | F & R | Yes | TS | 7'4" x 11'2 1/2" | 5'8" x 8'5" | 4'0" |
|
|
| Minimum Pit Depth | Minimum Overhead | Minimum Overhead (Up to 200 FPM) | Cab Height | Machine Room Requirements | Machine Room Drawing | |
|---|---|---|---|---|---|---|
| Up to 150 FPM | Up to 200 FPM | |||||
| 4'0" | 12'0" | 12'6" | 8'0" | 5'6" x 7'0" |
|
|
F – Front
R – Rear
SS – Single Slide
CP – Center Parting
TS – Two Speed
All Schumacher Elevator Company In-Ground Hydraulic Elevators meet or exceed all requirements set by the American Society of Mechanical Engineers (ASME A17.1).
Given dimensions are for planning purposes only and are not intended for construction use. Actual dimensions will be verified during the engineering process.
2022 code applications (and beyond) may require increased hatch width to be determined during the engineering process.
Custom designs available.
